Laminating and pressing lines for PCBs

Laminating lines for the production of printed circuit boards

The automated production of printed circuit boards and base material places high demands on laminating technology: These include taking temperature, pressing force and plate parallelism into account. BÜRKLE customers benefit not only from the customer-specific line design and optimised laminating processes but also from a sophisticated laminating concept with high output quality.

Technology portfolio for laminating and pressing lines for PCBs

  • Thermal oil hot presses
  • Electric hot presses
  • Cold presses
  • Feeding and destacking carts
  • Storage solutions
  • Lay-up stations

Laminating and pressing lines at a glance

Laminating systems
WORK CELL²: Small and medium series production
The WORK CELL² easily adapts to your production requirements. Whether as a stand-alone hot press or a complete laminating line with cold press and carriage: The small and medium series production of printed circuit boards is optimally implemented by our WORK CELL² laminating line.
Laminating systems
MULTILAM PCB press: Large series production
The MULTILAM PCB presses from BÜRKLE represent extensive handling, a high degree of automation and the possibility of large series production in the production of printed circuit boards. In cooperation with our customers, we design individual lines that are tailored to customer-specific requirements.

Laminating and press lines

Modular expandability for individual line concepts

With our modular line design, we enable you to design your own individual line concept. Convince yourself of our technologies and the diverse application possibilities of our machines and line components with the help of our line overview in our brochure.







Experience BÜRKLE laminating lines
Get first insights into our know-how
00

Technologies for laminating and pressing lines – Our brochure

You´ll find more information about our service and solutions in our brochure.

PCB Brochure
pdf - 3 MB

Your advantages of our laminating and pressing lines for PCBs

  • High-quality and proven laminating technology

  • Comprehensive process knowledge in all parameters

  • Easy maintenance of the lines

  • Expandable production capacities at any time

  • Hot presses with long service life due to state-of-the-art design

  • Cold presses with low energy consumption and efficient production
